1500 Watt Power Inverter with Battery Charger and Transfer Switch

Model Number: PWRIC1500W
Our price: $ 329.00
Quantity
1500 Watt Power Inverter with Battery Charger and Transfer Switch
1500 Watt Modified Inverter Charger with Transfer Switch AC Input 1500 Watt 12 Volt to 120 Volt Inverter Charger with Transfer Switch DC to AC Inverter Charger 1500 Watts

PWRIC1500W Overview:  Do you need a power inverter to supply back up power for your home or an inverter charger for your RV or boat? The AIMS 1500 watt modified sine power inverter with built in charger and transfer switch is designed to meet your back up or mobile power inverter needs.

The unit is a 1500 watt power inverter, with a 12 volt dc input. This inverter charger has a built in transfer switch which allows you to plug this inverter into a regular ac outlet in your home, when the power goes out, this power inverter automatically switches to run off of your battery bank. The charger which is built into this power inverter outputs 10 dc amps of charge to keep your batteries full, so when the power goes out they are ready to supply power to this back up power inverter.

The most common use for this modified sine inverter charger is to back up sump pumps in your basement. This unit is built to last and has been designed with sump pumps in mind. This AIMS power has produced this unit for nearly a decade and it is a very high quality power inverter charger. If you are looking for a more powerful inverter charger, we have 3000 watt inverter chargers available in both pure sine and modified sine.


Features:

  • 1500W max continuous power
  • Modified sine wave
  • Green LED indicates ac input power is functional and battery is charging
  • Transfer switch automatically switches when city power is lost
  • Red LED indicates ac input power is not functional and battery is being used
  • Dual ac receptacle
  • Over Temperature protection
  • Over Load protection
  • Single cooling fan operation
  • ac cable included to connect to shore power
  • Internally fuse protected
  • ac output short circuit protection
  • Aluminum case for optimal cooling
  • Pre-slotted mounting plate
  • Instruction manual
  • Free 1 year tech support
  • 1 Year Warranty Parts and Labor

Specifications:

  • Continuous output power: 1500 Watts 3000 Watt Surge
  • Surge power capability (peak power): 3000 Watts
  • dc input / operating voltage: 10 to 15 Volts
  • Output voltage: 120 Volts ac
  • Output wave form: modified sine wave
  • Output frequency: 60 Hz +/- 1 Hz
  • Battery low voltage alarm: 10.5 +/- 0.5 Volts
  • Battery low voltage shutdown: 10.0 +/- 0.5 Volts
  • Efficiency: 85-90%
  • No load draw: .6 amps
  • AC amps: 13
  • DC amps: 125
  • AC Output Socket Type: dual Type 2 -3 prong
  • High input voltage protection: 15V
  • Low input voltage shutdown: 10V
  • Internal fuse protection
  • 3-10 sec transfer time between loosing ac input power and switching to providing ac output power
  • Product size (L x W x H): 21 X 9.5 X 3
  • Weight: Unit: 12.1 lbs Boxed: 16.5 lbs
  • UL maximum recommended per outlet 1500W
